G1200
Exclusive to the G1200 are two additional options: HD drive for 45% more traction or higher travel speed (up to 19 km/h). This makes sense when materials need to be loaded, unloaded, or transported over longer distances.
![[4]g1200 tegelriek[2]](https://configurator.tobroco-giant.com/cache/5ede0c0937afa720ce8f346ae8103f90/[4]g1200-tegelriek[2].webp)
![[5]g1200grondbak[3]](https://configurator.tobroco-giant.com/cache/bfa94ec53f2862800671b85abb1fd03c/[5]g1200grondbak[3].webp)
![[3]g1200grondbak[2]](https://configurator.tobroco-giant.com/cache/fd2861b73b596f77e843ca711b3c0738/[3]g1200grondbak[2].webp)
Standard version
GIANT Compact mechanical quick change system
ROPS/FOPS safety roof incl. safety doors (L+R)
Luxury seat incl. safetybelt, armrest and extended backrest
1x Double acting hydraulic function on lifting arm, mechanical
Floating position on lifting cylinder(s)
Main switch
Tow coupling
Oil cooler
Lifting eyes
Technical specifications
Service weight ¹
1100 kg
Lifting capacity
1100 kg
Tipping Load ²
850 kg
Lifting height ²
2170 mm
Length without bucket
2210 mm
Machine height ³
2060
Width on standard tires
920 mm
Standard tires
23 x 8.50- 12 AS
Travel Speed
0-15 km/h
Engine
Kubota D902 (STAGE V)
Cylinders
3
Engine power
25 hp
Engine power (kW)
17,5
Fuel tank capacity
45
Oil tank capacity
52 l
Type
Hydrostatic 4 wheel drive
Transmission
Automotive control
Control
Drive back- and forward through electrical switch
Differential lock
Electric controlled slip differential
Final drive
4 heavy Poclain wheel engines
Driving hydraulics
65 l/min (350 bar)
Working hydraulics
28 l/min (150 bar)
Parking brake
Hydraulic multidisk brake
¹ Measured with earthbucket
² Measured with counterweight and driver ± kg
³ ᶟ Measured on standard tyres with safety roof
