G5000 X-TRA
This compact and agile mini shovel represents productivity, comfort, and a long lifespan. The G5000 X-TRA model features a lower front frame and is specifically developed for extremely heavy-duty work and tasks within construction and earthmoving. The G5000 models are designed to operate in small spaces and on rough terrain. The knuckle system, along with the low weight and compact dimensions, allows these machines to be highly maneuverable, enabling precise work.
![g5000x travolumebakmetbovenklem[2]](https://configurator.tobroco-giant.com/cache/4b82f807bc00416bcc4b49c0c4dd163f/g5000x-travolumebakmetbovenklem[2].webp)
![g5000x travolumebakmetbovenklem[1]](https://configurator.tobroco-giant.com/cache/c95753265a9f51034cad1e7105c7bdd3/g5000x-travolumebakmetbovenklem[1].webp)
![g5000x travolumebakmetbovenklem[3]](https://configurator.tobroco-giant.com/cache/0fda0a85182d8f51f713402d57283cc5/g5000x-travolumebakmetbovenklem[3].webp)
Standard version
GIANT hydraulic quick change system
ROPS/FOPS safety roof incl. rear window and safety doors (L+R)
Luxury air suspended seat with safety belt, armrest and extended backrest
Double acting hydraulic function on lifting arm (mechanical)
Floating position on lifting cylinder(s)
Hydraulic servicebrake on 4 wheels
Working light (halogen) front, on lifting arm
Main switch
Anti-theft protection with access code (not certified)
Tow coupling
Counterweight integrated into the bumper
Cyclone filter
Oil cooler
Technical specifications
Service weight ¹
5100 kg
Lifting capacity
3100 kg
Tipping Load ²
4390 kg
Lifting height ²
2850 mm
Length without bucket
4160 mm
Machine height ³
2550
Width on standard tires
1560 mm
Standard tires
11.5/80-15.3 AS
Travel Speed
0-10 km/h, 0-20 km/h
Engine
Kubota V3307-CR-TE (Stage V) with DOC and DPF
Cylinders
4
Engine power
75 hp
Engine power (kW)
55
Fuel tank capacity
77
Oil tank capacity
80 l
Type
Hydrostatic 4 wheel drive
Transmission
Automotive control
Differential
100% electrical differential lock on both axles
Final drive
16 tons axles with heavy planetary end drive
Pulling force standard
39.000 N
Pulling force 2 speed
60.000 N
Driving hydraulics
145 ltr/min (480 bar)
Working hydraulics
78 ltr/min (250 bar)
Parking brake
Hydraulic multidisc brake SAHR
¹ Measured with earthbucket
² Measured with counterweight and driver ± kg
³ ᶟ Measured on standard tyres with safety roof
