GT5048

TOBROCO-GIANT has elevated the design of the GIANT telehandler with the GT5048. The extensive knowledge from the 4548 TENDO and the latest technologies have been used to develop a modern telehandler in the 2x2-meter class. This means that the compact telehandler is only 1.91 meters high and 1.65 meters wide.

Configure now Request a price
gt5048volumebakmetbovenklem[2]
gt5048balenklem[4]
gt5048palletvork[2]
gt5048palletvork[4]

Standard version

GIANT Standard quick change system with hydraulic locking
ROPS / FOPS safety roof, incl. front and right window and frontwiper
Luxury seat with safetybelt, armrest and extended backrest
Double acting valve at the front (mechanical)
Transportlock
Hose rupture protection
Proportional Load Moment Protection (EN 15000)
Working light (halogen) front, on lifting arm
Battery, 77 Ah
Main switch
Anti-theft protection with access code (not certified)
Towing hook
Cyclone filter
Oil cooler

Technical specifications

Service weight ¹
2950 kg
Tipping Load ²
2490 kg
Lifting height ²
4800 mm
Length without bucket
3135 mm
Machine height ³
1970
Width on standard tires
1600 mm
Standard tires
10.00/75-15.3 AS
Travel Speed
0-10 km/h 0-25 km/h (met rijautomaat)
Engine
Kubota D1803 CR (STAGE V)
Cylinders
3
Engine power
50 hp
Engine power (kW)
36
Fuel tank capacity
38, 38
Oil tank capacity
75 l
Type
Hydrostatic four wheel drive
Transmission
Automotive control
Differential
Four-wheel steering
Final drive
8 tons axles, heavy planetary end drive
Pulling force
22600
Driving hydraulics
84 l/min (350 bar)
Working hydraulics
51 l/min (230 bar)
Parking brake
Disk brakes
¹ Measured with earthbucket
² Measured with counterweight and driver ± kg
³ ᶟ Measured on standard tyres with safety roof
